SXI Industrial Series Auger Spreader
Model # SXI720 / SXI865
The Meyer Industrial SXI Industrial Series V-Spreader combines Heavy Duty components and a high quality spread pattern to make the best use of your product. Our unique Rear Discharge System is unlike all others, incorporating two shaft drive vertical expellers. They are fed by an aggressive 3 auger system to power through pack manure, semi solids, sand sludge, slurry, litter, biosolids and certain lime and compost products. Rear discharge keeps your tractor and spreader clean while maximizing the value of the product you are applying.
PHOTOS
VIDEOS
Meyer SXI Industrial V-Spreader in Litter
Accurate Application / Consistent Performance
Meyer SXI Industrial Spreading Sludge
Spread Smarter - Check out the Meyer SXI!
Meyer SXI Industrial in Bed Pack
Make Better Use of your Manure / Litter / Byproduct
FEATURES
Pull Type or Truck Mount models available
The other guys talk about industrial features, we mean it. This machine is HEAVY DUTY in all the places you need it. Thicker tanks, larger augers, bigger drive components and added protections keep you on top of the game!
Meyer patented straight line flow - provides the ultimate spread performance. Better pattern, faster unload time, less horsepower & minimal wind drift!
3 auger system = only one of its kind. Lower 23" augers feed the rear door while the upper 16" auger levels the load forward and eliminates bridging. ALL SECTIONAL FLIGHTING!
The Meyer Dual Lower Auger design creates a wide profile at the bottom of the tank. This means that we can maintain the lowest load height in the industry with maximum capacity. Stops bridging too!
Heavy Duty Drivetrain
The Drive System of our Industrial Models have been recently upgraded. Resized drive sprockets reduce chain loading. This simple, yet efficient system has #140 final drive chains for your largest loads!
Automaitc Roller Chain Oiler is standard. Oils all roller chains eaech time you operate the tailgate. Eliminates reduced access and manure contamination associated with oil bath systems.
Simple
The SXI Drive is completely re-engineered for simplicity, easy maintenance, protection and auger speed adjustablity.
Independent Lower Auger Shear Bolt Protection is standard. Allows you to protect an obstructed auger while still unloading a majority of the load with the other auger. Bound to save you time!
Remote greasing on SXI models is standard allowing for convenient & safe maintenance.
Auger Speed Changes are quick and easy on standard PTO driven SXI models using this simple A-Plate design. Hydraulic drive augers optional!
Optional Variable Speed Auger Drive for adjustable rate control on the go!
Hydraulic Auger Speed options include: Single Motor System powered by 60 gpm ag tractor hydraulics (pull type only) or a Self-Contained Dual Motor System which includes pump, motor, cooler, reserviour & variable speed controller - just supply tractor/truck with PTO (pull type or truck mount).
3/8" sectional flighting on lower augers - doubled in critical areas. No paddles to wrap, freeze or wedge rocks like other brands.
Our revolutionary T-Post auger hold-down retains a nylatron (no maintenance) bushing and maintains tight auger tollerance to the tank floor. This system provides complete cleanout!
Vertical Twin Expellers pulverize material for a smooth, even application. This machine bands material across the back like a fertilizer spreader, unlike side delivery units that attempt to "chuck" all material out one side. All paddles are easily replacable and have no pivoting wearparts!
A Center Wedge dirverts material to the outside of the pattern for consistent spreading in all types of product - liquid or dry!
Rear Expellers with shock load couplers on all SXI models, no chains on rear of this spreader. Industrial models feature an overrunning clutch on the rear expeller system to eliminate backlash at shutdown!
New Belt Driven Expeller System
This multi-groove belt transfers power to the rear expeller system in a smooth, quiet fashion. You have to hear it to believe it!
Check out this Shock Load Coupler System! Drastically reduces "shock/stress" related to rocks, ice and foreign objects to your expeller drivetrain. This dampening system along with a torque disconnect clutch protect your expeller drive.
Large Door Opening
32x53" Door Opening dwarfs the others. Combined with the rear unload design, we can move tough loads out fast! Don't forget, all Meyer V-Spreaders have poly lined gate tracks (not steel on steel).
CV PTO Standard. 1000 RPM 1 3/8" on SXI720 model - 1000 RPM 1 3/4" on SXI865
All Meyer V-Spreaders feature a full channel frame. Stress from hitch, axles and payload is transmitted through the frame system. Take a look at the unibody designs on most V-Spreader!
HD Axles! SXI720 features 3.5" spindles / 10 bolt hubs with an optional high floatation axle set (pictured here). The SXI865 is equipped with the high floatation axle standard. It incorporates 4.5" spindles / 10 bolt hubs to accomodate 28Lx26 tires.
SXI720 standard axle system allows for 425/65x22.5, 550/45x22.5 or 600/50x22.5 tire options. The High Floatation axle is optional on SXI720.
Radial 28Lx26 Tires available with High Floatation Axle Package
This impressive Radial tire provides superior floatation when joined with our High Floatation Axle package. HF Axle is standard on SXI865 & optional on SXI720.
Swivel Hitch standard on SXI Industrial models
Hydraulic Lid Option
This optional hydraulic lid assembly provides cleaner transportation and less oder pollution. Right or left hinge is availabe and a port hole is standard equipment. Also avaiable is our hydraulic lock down package!
Scale Packages
SXI spreaders are available with a 5 point scale package. Standard or Nutrient Tracker versions available.
LED turn signal light package standard
